Model No.
|
SI-4236US4_SDCFEx-B
|
|
Item
|
CFEX-B/SD4.0 Dual card Reader
|
|
Certifications
|
CE, FCC, RoHS(compliance)
|
|
Material
|
High-quality Aluminum
|
|
Dimensions
|
80.00 x 80.00 x 23.00 mm
|
|
Interfaces
|
1 x USB-C upstream
1 x CFExpress Type-B socket
1 x SD USH-II socket
|
|
OS Support
|
Mac OS / Windows
|
|
Environment
|
A. Operating Temperature: 5°C ~ 55°C
B. Operating Humidity: 20%RH ~ 80%RH
C. Storage Temperature: -20°C ~ 50°C
D. Storage Humidity: 20%RH ~ 80%RH
|
|
Features
|
A. High quality aluminum body for optimized heat dissipation.
B. Dimensions: 80.0x80.0x23.0mm (Excludes footpad).
C. Functional LED for CFEx_B and SD activity indicator.
D. Supports USB4/Thunderbolt operation only; Configured for non-legacy PCIe 4.0 tunneling to CFexpress Type-B and SD UHS-II host interface. Does not support USB legacy fallback modes
E. Supports 1 x PCIe 4 NVMe CFexpress Type-B card transfer speed up to 3700MB/s (Theoretical value) or 1 x PCIe Gen 3 NVMe CFExpress type-B Cardsuper speed up to 1700MB/s (Theoretical value). Note: Test with AJA Desktop Software v17.13 or above.
F. Support SD4.0 UHS-II Card Reader port, super speed up to 312MB/s. (Backward compatible older versions of SD)
G. Supports hot-plug.
|
|
Power & Accessories
|
A. Retail Color Box x 1
B. User’s manual x 1
C. USB4 Type-C to Type-C cable length 0.5 Meter
|
