Model No.
|
SI-422KVM
|
|
Item
|
USB KVM Dock
|
|
Certifications
|
CE, FCC, RoHS(compliance)
|
|
Material
|
High-quality Aluminum
High-strength ABS+PC plastic
|
|
Dimensions
|
140.0 x 72.0 x 16.3mm.
|
|
Interfaces
|
1 x HDMI2.0 4K@60Hz port (output)
2 x USB-C Socket for PD power (input)
2 x USB-C for Displayport Alternate (input)
2 x Type-A USB2.0 ports
|
|
Button
|
1 x Hosts Option Switchover Button
|
|
LED
|
2 x PC1/PC2 Functional LED indicator (Dock)
2 x PC1/PC2 Functional LED indicator (Button)
|
|
Optional
|
1 x Retail Color Box
|
|
OS Support
|
Mac OS / Windows
|
|
Environment
|
Operating Temperature: 5°C ~ 55°C
Operating Humidity: 20% ~ 80% RH
Storage Temperature: -20°C ~ 50°C
Storage Humidity: 20% ~ 80% RH
|
|
Features
|
．2 to 1 KVM, supports 4K@60Hz output
．Support two USB-C PD3.0 charging 100W
．One button to switch the input
．Support 2 x USB-C power input
．Support 2 x USB-C to 1 x HDMI switch output
．Support 2 x type-A USB2.0
．Plug & play, automatically installs drivers.
．Backward compatible with USB3.0/USB2.0.
．Compatible TB3/4 & USB-C with DP function.
|
|
Advantages
|
[One-Key Switch]
Easy switching between dual hosts, the key extension design is more.
[Device Sharing]
A set of mouse and keyboard devices can be used between two hosts without plugging.
[High-Definition Video]
Equipped with HDMI2.0 ports, enjoy high-quality 4K@60H output.
[Device Sharing]
Mouse/keyboard/external device, no need to plug & unplug for hosts
[Cost Saving]
Users can switch through a set of devices to reduce clutter.
[Charging Station]
USB-C with PD 3.0 charging for mobile phones and tablets.
[Special Function]
Equipped with PC switch extension button and LED indicator.
|
|
Usage Scenario
|
[Home Sharing]
Multiple hosts/devices share and switch between 4K@60Hz displays.
[Video Creation]
With HDMI high-definition image output brings ultimate video work efficiency
[Work From Home]
Easy switching between two computers, participating in remote conferences and work from home at the same time.
[Financial Investment]
Financial management, banking, and financial trading cabinets.
[Plant Room]
Single console, improve control and productivity to save costs.
|
|
End-User
|
Home Sharing, Video Creation, Design Engineer, Control Room, Remote Office, Financial Institution, Remote Server, Factory Production, Data Center, Personal Use, General Consumer
|
