3 Port DP/HDMI® MST HUB

Model No.

SI-4073HDMI

Item

3 Port DP/HDMI MST HUB, USB-C to HDMIx1 and DPx2 Adapter

Certifications

CE, FCC, RoHS(compliance)

Material

High-quality Aluminum

Dimensions

73.0 x 70.50 x 11.6 mm

Interfaces

2 x HDMI2.0 4K@60Hz ports (output)
1 x Dispalyport1.4 8K/4K port (output)
1 x USB-C ports

Optional

1 x Retail Color Box

OS Support

Mac OS / Windows

Environment

Operating Temperature: 5°C ~ 55°C
Operating Humidity: 20%RH ~ 80%RH
Storage Temperature: -20°C ~ 50°C
Storage Humidity: 20%RH ~ 80%RH

Features

．Compatible TB3 or USB-C with DP function.
．Support 2x HDMI2.0/1x DP1.4 video output.
．Compatible TB3 or USB-C with DP function.
．Connect 3x independent displays to a HUB.
．Supports bus power and hot plug-and-play.
．Supports any conform DP Alt-mode device.
．Support 2x HDMI v2.0b and 1x DP1.4/DP++.
．DP++ for 1x 8K or 4K or 2K display output.

Advantages

[Efficient Conversion]
Suitable for dual HDMI computer transfer to TV, projector and monitor output.
[MST System]
It supports Mac OSX and Windows multi-stream transmission MST mode.
[Complete Functions]
USB cable power supply, hot-swappable, plug-and-play, portable accessories.
[Aluminum Matte]
The whole machine is made of aluminum alloy to optimize heat dissipation, with high-quality accessories for metal weight and matte appearance.
[Wired Device]
This machine is a pocket product with USB-C external cable all in one design.
[Silicone Protection]
With a soft and skin-friendly silicone protective cover, it is comfortable to hold and prevents product wear out.

Usage Scenario

[Video Editing]
HDMI dual-screen 4K output, equipped with video conversion equipment with various ports.
[Visual Design]
Output color saturated and undistorted, while proofreading and sharing large files with high efficiency.
[Medical Care]
Multi-screen testing instruments and multi-interface devices cross using images for real-time output.
[Financial securities]
Dual multi-screen high-definition picture quality display at the counter, high-efficiency synchronous transmission of data, audio and video.
[Home entertainment]
USB plug & play, specially designed for watching movies to share entertainment.

End-User

Business Management, Video Creation, Photography Editing, Visual Designers, UI/UX Designers, Product Design, Engineers, Architects, Medical Care, Financial Counters, Securities Analysis, Business Man, Teaching Sessions, Researchers, Bloggers, E-Sports, Family Sharing, General Consumer
